An Asse 1022 Dual Check Valve provides a practical way to support potable-water backflow protection where local code allows it. It is designed to help prevent reverse flow that could carry contaminants, corrosive substances, or carbonic acid into drinking-water lines. Approved devices are essential for safeguarding potable supplies and following local and national codes.
Asse 1013
Manufacturers such as Watts produce backflow preventers that meet ASSE performance requirements and certifications. These may include NSF/ANSI 61 and UL/FM approvals. These credentials help confirm that materials will not leach harmful substances and that assemblies can withstand pressure and stress. Although some authorities require higher-protection assemblies, an Asse 1022 device may be a reliable low-hazard option where the local authority permits it.
The Asse 1022 Dual Check Valve is valued for its small footprint, simple installation, and low maintenance costs. This guide explains Asse 1022 devices alongside higher-protection standards, including Asse 1013. It also outlines selection, installation, maintenance, and compliance steps so the unit can meet plumbing-code expectations and industry guidance.
Understanding Backflow And The Role Of Dual Check Valves
Backflow is a significant threat to water systems because it allows treated water to move backward. That backward flow may carry contaminants into potable lines and reduce the safety of drinking water. Local water authorities and adopted codes require measures that prevent this contamination.
Two main hydraulic causes lead to backflow incidents. Backsiphonage occurs when supply pressure drops and creates a vacuum that pulls water backward. Backpressure happens when downstream pressure exceeds supply pressure and forces water in the wrong direction. Knowing the difference between backsiphonage and backpressure matters because each condition can call for a different type of protection.
In homes, common cross-connections include irrigation systems, garden hoses, boilers, and chemical injection points. Commercial settings add booster pumps, closed-loop HVAC systems, and process equipment. Without the right device, these connections may become pathways for pollutants or unwanted substances.
Dual check valves, including the Asse 1022 model, are designed for low-hazard protection. They help prevent contaminants that may affect taste or odor but are not considered a direct health risk. The Asse 1022 Backflow Preventer is a compact solution for many applications identified in plumbing codes.
Proper device selection and installation are guided by codes and standards. ASSE performance requirements and ANSI-accredited development support product acceptance. Installers should follow local plumbing-code language and relevant guidance, such as the 2018 UPC and AWWA M-14, when applying Asse 1022 devices.
Common approved uses may include residential irrigation, HVAC makeup water, and selected commercial low-hazard cross-connections. Where hazards are higher, more protective devices are required.
| Problem | Cause | Suggested Protection |
|---|---|---|
| Backflow caused by suction | Supply pressure drop from mains, firefighting, or line breaks | Approved Asse 1022 device where allowed, or an air gap for stricter protection |
| Backflow caused by pressure imbalance | Pressure created by booster systems, elevated storage, or heated closed systems | Asse 1022 where low-hazard is approved, or RPZ where health hazards exist |
| Drinking-water contamination risk | Fertilizers, boiler chemicals, cleaning agents, or process liquids | Evaluate the cross-connection and install the approved protection level |
How Backflow Occurs In Plumbing Systems
Backflow is the backward movement of water from any source into the public supply. It can be caused by negative pressure or excessive downstream pressure. Both conditions can introduce contaminants and threaten potable water quality.
Why Low-Hazard Systems Use Dual Check Valves
A dual check valve uses two separate check mechanisms inside a single valve body. This redundancy protects low-hazard cross-connections against reverse flow. Asse 1022 devices are tested for low-hazard or nuisance-level risks and are commonly used where the authority allows this type of protection.
Understanding The Asse 1022 Dual Check Valve
The Asse 1022 Dual Check Valve is a compact backflow device designed for low-hazard potable water protection. It features two independent, spring-loaded check valves in series. That arrangement helps stop reverse flow and gives the device a second sealing point. It also supports serviceability while reducing contamination risk during pressure changes, brief backpressure events, or short disruptions.
Key Features And Functional Overview
Spring-loaded check mechanisms help the valve close positively when flow or pressure changes. Many models include serviceable internal parts and replaceable seats. That design can shorten maintenance time and reduce long-term ownership costs.
Manufacturers offer units in several materials, including bronze, brass, corrosion-resistant metals, and engineered plastics. Available sizes are designed to match common pipe diameters, pressure ratings, and potable-water system requirements.
Compact bodies, service access, and built-in test ports can make installation and inspection faster. The Asse 1022 Backflow Preventer fits tight spaces where larger assemblies cannot. Properly sized models can meet flow demands for common low-hazard applications.
Standards And Certifications That Support ASSE 1022 Devices
ASSE standards establish baseline performance tests and functional thresholds. Those tests are used to verify dependable operation under defined conditions. Many listed products exceed minimum requirements, which may reduce failure risk and support longer maintenance intervals.
NSF/ANSI 61 certification helps confirm that wetted materials are suitable for drinking water and do not leach harmful contaminants. UL/FM approvals can support confidence in durability, pressure resistance, and stress-tested performance. These listings give engineers, inspectors, and installers additional assurance when specifying equipment.
When combined with ANSI-accredited development, these approvals improve the Asse 1022 Dual Check Valve’s acceptance in plumbing codes and project specifications. For project teams seeking verified material safety and tested performance, ASSE 1022 features, NSF/ANSI 61, and UL/FM marks create a strong compliance package.
Comparing Related Standards And Products: ASSE 1013, ASSE 1012, And ASSE 1024
This section compares common backflow-protection options so the device can be matched to the hazard level and code requirement. It explains practical differences among RPZ assemblies, double-check devices, and other dual-check products used in U.S. plumbing systems.
Device selection should start with a clear hazard-level assessment. ASSE 1022 double-check assemblies suit low-hazard services such as irrigation and some HVAC makeup lines. In contrast, Asse 1013 RPZ devices are intended for high-hazard cross-connections where contamination could threaten health. Asse 1024 applies to reduced-pressure principle devices used where severe contamination risk may exist. Asse 1012 may apply when local rules call for specific dual-check devices or service-line configurations.
ASSE 1022 Versus ASSE 1013 And ASSE 1024
ASSE 1022 double-check devices rely on two check valves, and where applicable shutoff valves, to control backflow in low-hazard uses. ASSE 1013 RPZ devices include a relief valve that vents to atmosphere when internal pressure drops, providing a higher safety margin. Asse 1024 reduced-pressure principle devices use the same relief concept but apply to a broader set of severe contamination risks.
Testing requirements and procedure complexity vary by device type. RPZ units under Asse 1013 require more rigorous annual and post-event testing with relief valve verification. ASSE 1022 double-check devices require periodic testing of the check mechanisms, generally with simpler procedures than RPZ assemblies.
Where ASSE 1012 Or Similar Standards May Be Used
Asse 1012 defines requirements for certain dual-check configurations used in low- to moderate-hazard settings. Use this category when local code or the water authority accepts a dual-check style but specifies a different recognized standard beyond ASSE 1022.
Code requirements differ from one jurisdiction to another. Many municipalities following the 2018 UPC require ASSE 1013 RPZ for high-hazard cross-connections. Utilities may allow ASSE 1022 for low-hazard applications or specify Asse 1012-certified dual-check devices for certain service-line uses. Before installation, confirm the required protection level with the local water authority or authority having jurisdiction.
| Feature | ASSE 1022 | ASSE 1013 RPZ | Asse 1024 | Asse 1012 |
|---|---|---|---|---|
| Main application | Low-risk potable-water cross-connections | High-hazard cross-connections and health-risk protection | Serious contamination threats requiring reduced-pressure protection | Certain service-line dual-check applications |
| Protection level | Lower protection level | High hazard | High hazard | Low or moderate hazard |
| Atmospheric relief | No relief valve | Required relief valve | Required relief feature | Not typically included unless the product standard specifies it |
| Typical testing | Routine check-mechanism verification | Annual and post-event testing with relief verification | Annual reduced-pressure assembly testing | Inspection frequency set by local requirements |
| Common applications | Residential irrigation and selected HVAC makeup lines | High-hazard systems involving toxic or harmful fluids | Reduced-pressure protection for severe hazard sources | Specific service uses approved by local code or utility |
| Common code treatment | Accepted in many low-hazard cases | Often required where contamination could affect health | Used where serious contamination protection is required | Selected where code or utility language specifically calls for it |
For an ASSE 1022 comparison with RPZ units, consider both safety margin and testing needs. RPZ versus double-check decisions depend on hazard assessment, local code, and water authority rules. When in doubt, choose the higher protection level specified by the authority having jurisdiction.
Installing, Maintaining, And Staying Code-Compliant
A correct Asse 1022 installation starts with careful planning. Place dual check valves in an easily accessible area and follow the manufacturer’s orientation guidelines. Maintain enough space for service, testing ports, and unions. This lets certified testers access fittings without unnecessary disassembly.
Use sound piping practices so the installation does not create a new cross-connection risk. Do not place the device where downstream cross-connections can bypass or undermine the protection. Install shutoffs, unions, and drain provisions according to manufacturer instructions and local codes. Make sure unions and test cocks remain accessible for routine service and backflow testing.
Maintenance schedules are set by local regulations and water authority directives. Many areas require annual inspections and backflow tests by certified professionals. Detailed records of service and test results are important for proving compliance during audits and permit reviews.
Certified testers can provide documentation that meets many regulatory and water-authority requirements. AWWA M-14 can be used as a reference for inspection, maintenance, and backflow-prevention practices. Following these guidelines can reduce downtime and detect wear before leaks or failures occur.
Choose devices with recognized listings to simplify approval. Products with ASSE approvals and NSF/ANSI 61 certifications are often easier for inspectors to accept. UL/FM compliance may also be important for commercial, industrial, or fire-protection connections that require third-party recognition.
Before installation, learn the applicable plumbing code edition and water authority rules in your area. Certain jurisdictions may require an RPZ rather than a dual check valve. Confirm permitting requirements and verify that the selected Asse 1022 installation meets local standards before work begins.
Create a consistent record-keeping process for the device. Store manufacturer cut sheets, test certificates, and repair invoices with a map of the device location. This simplifies future inspections and supports transparent compliance during regulatory reviews.
Product Selection Guidance And Where To Buy
Choosing the right device means matching size, pressure rating, and materials to the plumbing system. Make sure the Asse 1022 Dual Check Valve fits the pipe diameter and peak flow. Check pressure ratings against maximum working pressure, surge conditions, and site-specific operating conditions.
Material compatibility is a key consideration in potable-water systems. Choose brass, bronze, or NSF/ANSI 61-certified plastics to avoid corrosion or leaching. Check manufacturer data for chemical resistance, especially if local water chemistry is aggressive or unusual.
Verifying certifications can make approval and inspection easier. Confirm that the product lists ASSE 1022 compliance and NSF/ANSI 61 certification. If local codes demand UL or FM approval, confirm those marks before purchase.
Consider supplier reputation when buying ASSE 1022 devices. Authorized dealers can provide genuine products, documentation, and warranty assistance. Installation Parts Supply is a reputable distributor that stocks certified units and can help with model selection.
Warranty coverage and pricing rules can affect the final purchase cost. Check manufacturer warranty limits, authorized-sale requirements, and MAP pricing rules that may prevent online price display. Some suppliers show final pricing only in the cart while still preserving warranty coverage through authorized sales channels.
How To Choose Materials
- Match pipe size and flow to the Asse 1022 Dual Check Valve model.
- Prefer components with NSF/ANSI 61 certification for potable systems.
- Check the Asse 1022 Backflow Preventer pressure rating and surge tolerance before installation.
Reliable Supplier Tips
- Purchase from certified or authorized dealers so documentation is available for inspections.
- Choose vendors that offer sizing support and warranty handling.
- Installation Parts Supply often provides certified stock and model guidance.
| Selection Factor | Details to Confirm | Reason It Matters |
|---|---|---|
| Size and Flow | Pipe size, peak GPM, and manufacturer sizing chart | Ensures the device can handle demand without unnecessary restriction |
| Material compatibility | Approved metals or certified plastics for potable water | Reduces leaching concerns and supports longer service life |
| Pressure and surge capacity | Rated operating pressure plus expected surge tolerance | Ensures safety under normal and peak conditions |
| Compliance markings | Required approvals for code, utility, or project specifications | Supports code compliance and regulatory acceptance |
| Supplier | Dealer authorization, paperwork, and warranty support | Ensures genuine Asse 1022 Backflow Preventer and post-sale support |
| Warranty and final cost | Coverage limits, pricing visibility, and replacement support | Helps buyers understand total cost and warranty protection |
Summary
ASSE 1022 double-check valves are dependable, space-saving choices for low-risk backflow prevention where local authorities allow them. The Asse 1022 Dual Check Valve uses two spring-loaded checks and materials that meet NSF/ANSI 61 and ASSE standards. This helps reduce contamination risk in approved uses such as irrigation systems and certain HVAC makeup lines.
Choosing the right device depends on hazard level and code compliance. Use an Asse 1022 Backflow Preventer for low-hazard scenarios. For high-hazard protection, use ASSE 1013, ASSE 1024, or reduced-pressure assemblies. Proper selection streamlines permitting and improves water-system safety.
For backflow-prevention compliance, follow manufacturer instructions and local plumbing-code requirements. Where applicable, this may include the 2018 UPC, local amendments, and water authority rules. Purchase certified products from trusted suppliers. Verify ASSE, NSF/ANSI 61, and UL or FM listings for approvals and reliability.
Correct device selection, precise installation, and regular maintenance are essential. These steps, supported by certified devices and qualified testers, help safeguard potable water. They also support regulatory acceptance. Following these practices helps the Asse 1022 Dual Check Valve or other backflow solutions perform reliably.
